Technical Capablities

We believe in " You’ll never have a product or price advantage again. They can be easily duplicated, but a strong customer service culture can’t be copied."

Melting Alloys

Carbon Steel, Alloy Steel, Stainless Steel, Copper Based Alloys, Duplex Steel Alloys & Super Alloys like Hastalloy, Stellite & Monel Matching ASTM, AISI, DIN, GOST, JIS, BS, SAE & IS standards

Weight and Size Limit

Weight: 10 grams – 51 Kg.
Size : 350MM Length X 350mm W X 350MM hight
Citrate shape in parts.

Tolerance

Permissible Deviations on Dimensions, as per IS 11166:1993 Class 2
Nominal Dimensions		Overall Dimensions in mm.								Center Distance Tolerance For Holes & Bosses
of Rough Casting		Up to 6	Over 6	Over 10	Over 18	Over 30	Over 80	Over 180	Over 300
Over	Up to		Up to 10	Up to 18	Up to 30	Up to 80	Up to 180	Up to 300	Up to 500
	6	± 0.10	± 0.12	± 0.15	± 0.20	± 0.25	± 0.25	± 0.30	± 0.35	± 0.12
6	10		± 0.12	± 0.15	± 0.25	± 0.25	± 0.30	± 0.35	± 0.45	± 0.12
10	18			± 0.20	± 0.30	± 0.35	± 0.35	± 0.40	± 0.55	± 0.15
18	30				± 0.30	± 0.40	± 0.45	± 0.50	± 0.65	± 0.25
30	80					± 0.55	± 0.55	± 0.60	± 0.75	± 0.35
80	180						± 0.60	± 0.70	± 0.90	± 0.45
180	300							± 1.00	± 1.15	± 0.70
300	500								± 2.00	± 0.90

Minimum Order Quantity

Minimum 60 kg casting for non regular material grade

Surface Finish:

Surface finish of our Castings will be 1.6 RA Value.

Tools Design and Manufacturing

In house well equipped design tool room to manufacture multi-cavity complex dies.
Associations with tool rooms equipped with CNC wire cut, spark erosion, 3D pantograph machine.

ValueAddition

CNC & VMC Machining
NDT – RT / MP / LP
All types Special Heat treatment
All types Physical tests
Additional Tests – Surface roughness test, Salt spray test, IGC Practice B, F, Impact Test
Coating – Zinc passivation, Electro Polishing, Acid Pickling, Blackening

True Just-in-TIme Delivery
– Every Time

In today’s fluctuating market, it’s almost impossible to keep inventories low… unless you’re working with Maruti Inv Steel Casting. Get an on-time delivery rate of almost 100% with Maruti Inv Steel Casting’s unique 56 work-in-progress inventory turns annually. Plus, with our Just-In-Time delivery, we can respond rapidly to an engineering change for an existing part or a new product launch.

Technologically Advanced Processes and People

Maruti Inv Steel Casting’s state-of-the-art production facilities provide you with unrivaled process control, repeatability, and reliability. To ensure your needs are met, Maruti Inv Steel Casting has a dedicated team of 25 award-winning engineers work with you every step of the way. They’ll provide you with the technical assistance and sound design that results in lowest overall cost and component design excellence

Precise and Highest Level of Quality

Our quality is second to none. We’ll deliver your products to the highest quality standards, on-time resulting in the lowest total cost. When it comes to your engineering components, you can’t always trust your reputation to the supplier with the lowest piece price.

Call us today at +91 98251 69267 or Email us at support@marutisteelcasting.com
